BLOG

showing 61 - 75 of 120 post(s)

Rules References

08-03-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
The hands are considered part of the bat.

The hands are part of a person's body. If a pitch hits the batter's hands the ball is dead; if he swung at the pitch, a strike is called (NOT a foul). If he was avoiding the pitch, he is awarded first base.

Rules: 2.00 PERSON,
TOUCH, STRIKE (e) and 6.05(f) Official Baseball Rules



Selecting The Right Bat Weight- Baseball

08-03-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
The reason we make some models in -2 rather than -3 (and the truth is that no maple bats should be made as light as -3 period) is that we understand after getting feedback on tens of thousands of bats what parameters a bat model needs to both perform and hold up. Maple is a heavy, dense wood and thus far, the best performing wood for bats. However, when bats are made with billets that are too light, they perform more like ash and break more readily than ash. Maple is a less flexible wood than ash so light maple does not have the performance advantage over ash and breaks easier than ash due to it's stiffness. This is why the maple backlash in MLB has come about.


Baseball Field Layout

08-01-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
THE PLAYING FIELD.The field shall be laid out according to the instructions below. The infield shall be a 90-foot square. The outfield shall be the area between two foul lines formed by extending two sides of the square, as in Diagram 1. The distance from home base to the nearest fence, stand or other obstruction on fair territory shall be 250 feet or more. A distance of 320 feet or more along the foul lines, and 400 feet or more to center field is preferable. The infield shall be graded so that the base lines and home plate are level. The pitcher's plate shall be 10 inches above the level of home plate.


Video Replay

07-01-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
Until this season, video review was only allowed for boundary calls involving home runs, and it happened at the discretion of the umpires, who would leave the field to look at replays and then return to make their decision known.


New MLB Rule 7.13 - Video Replay Procedure

06-26-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
OFFICIAL BASEBALL RULE 7.13
Note: The rule is considered "experimental" for the 2014 season


Illegal Bat Penalties

06-23-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »

Before the batter steps into the box: Under all codes, if detected, the umpire can direct the player to switch to a legal bat. There is no penalty.

The batter is in the box but has not seen a pitch: Under NFHS and pro rules, the batter is considered to have used the illegal bat as soon as he steps into the box.



J.D. Drew's 1997 Homer

06-05-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
Background::J.D. Drew hit a monster home run during the 1997 season, but it hit a tree in flight (while still 85' off the ground) so the length of the homer could not be determined. After reading an article in the newspaper about this problem, including some estimates by the coaches and a request for some help ("Now there's a science problem for you," FSU coach Mike Martin said.


MLB's Zone Evaluation System

06-04-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
Major League baseball replaced the QuesTec system with Zone Evaluation in all ballparks during the 2009 season, with triple the data collection. The system records the ball's position in flight more than 20 times before it reaches the plate. After each umpire has a plate assignment, the system generates a disk that provides an evaluation of accuracy and illustrates any inconsistencies with the strike zone. Zone Evaluation operated successfully in 99.8 percent of the 2,430 games played during the 2009 season, according to MLB.


The QuesTec Information System

05-30-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
QuesTec is a digital media company known mostly for its Umpire Information System (UIS) which is used by Major League Baseball for the purpose of providing feedback and evaluation of Major League umpires. The QuesTec company, based out of Deer Park, New York, has been mostly involved in television replay and graphics throughout its history. In 2001, however, the company signed a 5-year contract with Major League Baseball to use its pitch tracking technology as a means to review the performance of home plate umpires during baseball games. The contract has continued through the 2008 season by annual extension and topped out at 11 ballparks. In 2009 it was replaced by MLB's Zone Evaluation.


What About Filling the Cavity with Superballs?

05-27-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
This is an interesting question. A more generic question is whether there is some substance that is compressible (so as to store energy) but not so compressible that it does not return the energy to the ball. This is a question that is worth thinking hard about and worth doing some experimental measurements to study the effect. Such experiments are currently in the planning stage.


But is there a "trampoline" effect?

05-22-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
The trampoline effect is quite well known in hollow metal bats. The thin metal shell actually compresses during the collision with the ball and springs back, much like a trampoline, resulting in much less loss of energy (and therefore a higher batted ball speed) than would be the case if the ball hit a completely rigid surface. The loss of energy that I referred to comes mostly from the ball. During the collision, the ball compresses much like a spring. The initial energy of motion (kinetic energy) gets converted to compressional energy (potential energy) that is stored up in the spring. The spring then expands back out again, pushing against the bat, and converting the compressional energy back into kinetic energy.


What negative effect does this have on performance?

05-19-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
The efficiency of the bat in transferring energy to the ball in part depends on the weight of the part of the bat near the impact point of the ball. For a given bat speed, a heavier bat will produce a higher hit ball speed than a lighter bat. That is why the head of a golf driver is heavier than that of an iron: you want to drive the ball further. By reducing the weight at the barrel end of the bat, the efficiency of the bat is reduced, giving rise to a reduced hit ball speed and less distance on a long fly ball. This is the downside of using a corked bat.


The Physics of a Corked Bat

05-16-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
The natural frequency of wooden bats is around 250 cycles per second, or 250 Hertz. Because the ball leaves the bat so soon (1 millisecond), the energy transfer to the ball is not too efficient. If the bat has been hollowed and corked, it's no longer as stiff and it will get an even lower natural frequency and an even less efficient transfer of energy to the bat. The baseball bounces off the bat faster than the cork can store the energy that could be put back in the ball. The cork might deaden the sound of a hollowed out bat, but it doesn't propel the ball. It can't. So, balls hit with corked bats don't go as far.


Bat Physics. The "Sweet Spot"

05-13-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
A baseball bat has three "sweet spots"; one of them is called its "center of percussion" (COP). That's physicist talk for the point where the ball's impact causes the smallest shock to your hands. If you hit a baseball closer to the bat's handle than to the center of percussion, you'll feel a slight force pushing the handle back into the palm of your top hand. If you hit the ball farther out than the COP, you'll feel a slight push on your fingers in the opposite direction, trying to open up your grip. But if you hit the ball right on the COP, you won't feel any force on the handle. To find the COP on a bat, try this simple activity.


Curve Ball Physics

05-09-2014  |  By: X Bats |  (0) Post comment »  |  Read comments »
The secret to understanding a curveball is the speed of the air moving past the ball's surface. A curve has topspin, meaning that the top of the ball is moving in the same direction as the throw and the OPPOSITE direction of air flow relative to the direction of the throw. Vice versa for the bottom of the ball. It moves in the SAME direction as the air flow relative to the throw. See Bernoulli's principle, which says that the lower velocity of the air over the ball creates more pressure on the ball, which is what makes the curveball break downward. (Thanks to Lizbeth for correcting this info)
